Powertrain and Performance
With acceleration and tractive power typical of sports cars – the new Taycan 4S draws on the strengths of the Taycan Turbo and Turbo S. The rotor of the permanently excited synchronous motor on the rear axle has a length of 130 millimeters, 80 millimeters shorter than the rotor on the Taycan Turbo S and Taycan Turbo resulting in more compact packaging and reduced weight. The pulse-controlled inverter used on the front axle in the Taycan 4S operates with up to 300 amps, and the inverter on the rear axle with up to 600 amps, further connecting it to the Taycan Turbo.
With two permanently excited synchronous motors on the front and rear axles—in other words all-wheel drive—as well as a two-speed transmission on the rear axle, the drive architecture comprises the same main technical highlights as the rest of the Taycan family. The same also applies to the intelligent charging management and exemplary aerodynamics. With a cd value from 0.22, the aerodynamics make a significant contribution to reducing energy consumption.
Centrally Networked Chassis Systems
Porsche uses a centrally networked control system for the Taycan chassis. The integrated Porsche 4D Chassis Control analyzes and synchronizes all chassis systems in real time. As standard, the Taycan 4S features adaptive air suspension with three-chamber technology including electronic damper control PASM (Porsche Active Suspension Management).
The Taycan 4S has six-piston fixed-calipers in red on the front axle and four-piston calipers in red on the rear axle, with internally vented cast iron brake rotors. The brake rotor diameters are 360 millimeters for the front wheels and 358 millimeters on the rear wheels. Regenerative braking performance remains high: maximum regenerative force is 0.39 g, with recuperation of up to 265 kWh.
Charging
When plugged into an 800-volt high-speed DC charging station, the maximum charging capacity (peak) is 225 kW for the Performance Battery or 270 kW for the Performance Battery Plus. With either battery, and under ideal circumstances, charging from 5% to 80% state of charge can occur in as little as 22.5 minutes. Standard 400-volt high speed DC charging occurs at 50 kW, and an optional Booster increases the charge speed to 150 kW. AC charging can be done at any J1772 compatible charging station or at home, with the included charger.
Porsche DNA
Distinguishing features of the Taycan 4S compared with the Turbo and Turbo S include the aerodynamically optimized 19-inch Taycan S Aero wheels and brake calipers painted in red, typical of Porsche's two-door sports cars. The front fascia with new geometry, side skirts and rear diffuser in black ensure further visual differentiation. LED headlights including Porsche Dynamic Light System Plus (PDLS Plus) are equipped as standard.
