2015 ULTRA4 4500 Modified
FollowVehicle Quick Facts
Profile ID: 62500
Year: 2015
Make: ULTRA4
Model: 4500 Modified
Markets: Off Road
Vehicle Type: American
Contact: Come Get Ya Some Off-road
Vehicle Story
Custom built Jimmys 4x4 chassis built to the specs of the Modified 4500 class. It has a LS421 engine built by Limitless Performance in Arkoma, OK. The engine has a Dart block, Brodix Heads, a Fast Intake, a Comp Cam, Custom Headers and an ATI balancer. The transmission is a Maximum built Turbo 400 with a mild stall for KOH, The transfer case is an Atlas II Race Case. The power is transferred to the 5:43 ratioed Gear Works 10" third members through Tom Woods Custom Driveshafts. Moving through the third members, the power is again transferred through Branik Motorsports 40 spline axle shafts to the 17" Raceline wheels wrapped with 37" DOT Yokohama Geolander Mt tires. We are running Spidertrax Axle Housings, Radflo Suspension (14"x 2.5" 4 tube bypass shocks and 14"x2.5" Coilovers, A Warn winch with Custom Splice mainland Rope, Steinjager Rod Ends, Branik Motorsports Custom Link Bars, Sway bars and Sway bar arms. Our braking system is all Willwood 6 piston calipers with 14" vented Rotors and dual master cyclinders. Our safety gear starts with our PRP Suspension seats, 5 point PRP Certified Harness Belts and Custom built PRP window nets. PRP also builds our Limit Straps on the suspension. We have won Multiple Regional Championships both East and West Coast, A National Championship, as well as earning a win at Crandon International Speedway, and 2 huge wins at KOH in the EMC race for the modified class. This car is always a contender and it is because of all the top Notch parts. Additional marketing Partners include Yukon Gear and Axle, Scranton Truck and Trailer, CDL Academy, Patterson Wellhead, Daily Custom Meats, Sign Planet, PSC Steering, Optima Battery, Pine Rock Soap Shack, Indian Territory Stone
Tech Sheet
Chassis
- Brake Rotors: Wilwood Disc Brakes - 14" vented
- Brakes: Wilwood Disc Brakes - 6 piston Calipers
- Coilovers: Radflo Suspension - 14"x2.5" 4 tube bypass shocks, 14" x 2.5" coilovers
- Frame: Jimmy’s 4×4 - Modified 4500 Class Chassis
- Limit Straps: PRP Seats
- Plumbing/Fittings/Hoses: Russell Performance - Russell Performance
- Power Steering Pump: PSC Motorsports - PSC Motorsports
- Rod Ends: Steinjager
- Subframe Connectors: Branik Motorsports - Custom Link Bars
- Sway Bars: Branik Motorsports
- Winch: Warn Industries, Inc. - Warn 9500XP
Drivetrain
- Axle Housing: Spidertrax Off-Road
- Axle/CV shaft: Branik Motorsports - 40 spline
- Differential: GearWorks - 10" third members
- Driveshaft: Tom Wood’s Custom Drive Shafts - Custom Driveshafts
- Flywheel: TCI Automotive - TCI Automotive
- Ring/Pinion: GearWorks - 5:43 ratio
- Tires: Yokohama Tire Corporation - Yokohama 37" Geolander MT
- Transfer Case: Advance Adapters - Adnaved Adapter Atlas II race case
- Transmission: Maximum Transmissions - Turbo 400 with a mild stall
- Wheels: Raceline Wheels - Raceline 17" Beadlock
Engine
- Battery: Optima Batteries - Optima Yellow Top
- Block: Dart Machinery, LTD
- Camshaft: Comp Cams - Comp Cams Custom grind
- Cylinder Heads: BRODIX Cylinder Heads
- Exhaust Components: MagnaFlow - Magnaflow 5" Round race
- Fans: Spal Automotive USA - Spal 16", 14", 7"
- Fuel Injection: FAST- Fuel Air Spark Technology - FAST
- Intake Manifold: FAST- Fuel Air Spark Technology - FAST
- Plumbing/Fittings: Russell Performance - Russell Performance
Interior
Shops
- Project Manager: Come Get Ya Some Off-road
